ITEM | Unit | OGS-1 | |
PRODUCT | Theoretical output | Pcs/h | 500 |
Max. Volume | L | 7.0 | |
Max. height | MM | 360 | |
Max. diameter | MM | 120 | |
MOULD | Number of cavities | / | 1-2 |
Mould plate dimension (LxH) | MM | 490×470 | |
Mould thickness | MM | 250 | |
Mould opening stroke | MM | 230 | |
ELECTRICAL | Power | / | 220-380V 50-60Hz |
Total power | KW | 11 | |
Heating power | KW | 10 | |
MACHINE | Main body dimension (LxWxH) | M | 1.6×0.65×2.0 |
Main body weight | KG | 600 | |
Pre-heater dimension | M | 1.4×0.6×1.4 | |
Pre-heater weight | KG | 300 | |
Future:
1. Adopting double crank to adjust mould, heavy locking mould, stable and fast, Adopt infrared oven to heat the perform, the perform rotated and heated equally.
2. The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow. It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
3. The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
4. The machine can be operated in the step-by-step mode and the semi-auto mode.
5. The machine is small with low investment, easy and safe to operate.
Packing Details:
Semi automatic PET bottle blow moulding machines are packed with wooden pallets, covered with plastic film; auxiliary machines and spare parts are packed with wooden boxes. The loading to containers is done according to weight balance, every package's position is fixed in containers to avoid moving. The photos of whole delivery will be sent to you for reference.
