Introduction

Our packaging department is focusing on a broad range of PET preform molding systems, closure moulding production line, stretch blow moulding equipments, and extrusion blow moulding machines. Injection mold department is dedicated in various plastic mould, such as the molds for automobiles, pallet, crate. Mega services to the global plastics industry.

Specification

Description		AXA-178PET
Injection Unit		AXA-178PET
Screw Diameter	MM	50
Shot Size (PS)	CM3	436
Shot Weight	G	499
Injection Rate	G/S	213
Injection Pressure	MPA	142
Screw Speed	R.P.M	0-133
Clamping Unit
Clamping Tonnage	KN	1780
Toggle Stroke	MM	435
Space Between Tie-Bar	MM	470×470
Max. Mould Thickness	MM	520
Min. Mould Thickness	MM	180
Ejector Stroke	MM	135
Ejector Tonnage	KN	50
Others
Max. Pump Pressure	MPA	16
Pump Motor Power	KW	18.5/18.2
Heater Power	KW	14.7
Machine Dimension	M	5.15×1.43×2.21
Machine Weight	TON	6.5
Oil Tank Capacity	L	300

Features

1. This high-performance control system provides the ideal communication between the injection molding machine and the operator. The uniform operating concept and logical, clear structure of the functions make machine operation easy and user-oriented.

2. Optimized special L/D 25:1 screw, requiring a longer machine base, is driven by a high output motor for dramatically improving the plasticizing of the PET material to ensure the quality of the PET pre-form. Increased ejector force consistently ensures the finished parts are automatically ejected.

3. The optuimized kinematics of the proved 5-point toggle represent economical speed and power processes. This allows high sensitivity in the opening and closing processes and protects injection moulds from excessive wear and tear. The fast mold closing device is optimized to shorten the cycle time.

4. Automatic Mould-height adjustment by hydraulic motor through the gears system ensures fast and constant settings to different mold height, achieve platen parallelism and consistent tonnage. The photocell detects function to insure the high precision.

5. The energy-saving hydraulics are fitted with sound reduced and are made of high-quality components. They allow much greater forces to be transferred and enable very uniform and precision movements of the machine.

Details
